Standard hydraulic cylinder according to DIN and ISO
Hydraulic cylinders with mounting dimensions according to DIN ISO 6020/6022
Honed surfaces, geometric accuracy, long service life. Compliant with mounting dimensions and accessories according to applicable standards, these series convince through their inner Hänchen values.
In typical Hänchen quality with matched sealing elements, these hydraulic cylinders meet the highest technical requirements for safe and reliably controlled drives. The Hänchen standard cylinders comply with the mounting dimensions according to DIN ISO 6020/6022.
Hänchen develops and produces high-quality hydraulic cylinder for a wide range of requirements.
- Extremely long service life
- Mounting dimensions according to DIN and ISO
- Tools according to DIN ISO 8132
- Extremely long maintenance intervals
- Honed sliding surfaces
- High accuracy of the components
DIN / ISO standards for hydraulic cylinders
There are numerous standards for hydraulic cylinders: The dimensional standards are intended to guarantee interchangeability between manufacturers. The following standards apply to round cylinders: DIN ISO 6020-1, DIN ISO 6022 and the tools for standard hydraulic cylinders such as rod ends fall under DIN ISO 8132.
The dimensional standard therefore describes the mounting dimensions of standard cylinders, but not the quality or material of the hydraulic cylinder.
See also: https://www.iso.org
Tip: Always compare standard dimensions between manufacturers, as the standard allows large tolerances.
Series of Hänchen standard cylinder DIN/ISO
Double-acting single-rod cylinders
Standard hydraulic cylinder DIN/ISO with the same mounting dimensions in comparison:
left Hydraulic cylinder according to ISO 6022 with cushioning
right Hydraulic cylinder series 550 without cushioning
Accessories and tools for standard cylinder DIN/ISO
Mounting elements, assembly tools and system components
You can find our available standard accessories according to ISO 8132 / 8133 and other tools in the HÄKO product configurator to match your selected cylinder.
Technical Data of Hänchen standard cylinders DIN/ISO
Standard-compliant hydraulic cylinders
Type of effect: single-rod cylinder | Sealing systems: basic design, Servocop®, Servofloat® |
Speeds: up to 0.5 m/s | Stroke: 1 - 6,000 mm
You can perform the hydraulic calculation of hydraulic cylinders, as well as the selection of suitable accessories and data sheets, in our HÄKO product configurator.
| Series 160 DIN ISO 6020-1 |
Series 550 DIN ISO 6022 |
|||||||
| Bore (mm) |
Rod Ø (mm) |
Force F1 | F2 (kN) |
Pressure max. (bar) |
Force F11 | F2 (kN) |
Pressure max. (bar) |
|||
| 25 | 14 | 7,9 | | 5,4 | 160 | --- | --- | ||
| 32 | 18 | 12,9 | | 8,8 | 160 | --- | --- | ||
| 40 | 22 25 28 30 |
20.1 | 20.1 | |
14.0 --- 10.3 --- |
160 --- 160 --- |
31.4 | 31.4 | |
--- 19.1 --- 13.7 |
--- 250 --- 250 |
|
| 50 | 28 30 36 40 |
31.4 | 31.4 | |
21.6 --- 15.1 --- |
160 --- 160 --- |
49.1 | 49.1 | |
--- 31.4 --- 17.7 |
--- 250 --- 250 |
|
| 60 | 40 50 |
--- --- |
--- --- |
70.7 | 70.7 | |
39,3 21,6 |
250 250 |
||
| 63 | 36 45 |
49.9 | 49.9 | |
33,6 24,4 |
160 160 |
--- --- |
--- --- |
||
| 80 | 45 50 56 60 |
80.4 | 80.4 | |
55.0 --- 41.0 --- |
160 --- 160 --- |
125.7 | 125.7 | |
--- 76.6 --- 55.0 |
--- 250 --- 250 |
|
| 100 | 56 60 70 80 |
125.7 | 125.7 | |
86.3 --- 64.1 --- |
160 --- 160 --- |
196.3 | 196.3 | |
--- 125.7 --- 70.7 |
--- 250 --- 250 |
|
| 125 | 70 80 90 100 |
196.3 | 196.3 | |
134.8 --- 94.6 --- |
160 --- 160 --- |
306.8 | 306.8 | |
--- 181.1 --- 110.4 |
--- 250 --- 250 |
|
| 140 | 100 | --- | --- | 384,8 | | 188,5 | 250 | ||
| 160 | 90 110 |
321.7 | 321.7 | |
219,9 169,7 |
160 160 |
--- --- |
--- --- |
||
| 200 | 110 140 |
502.7 | 502.7 | |
350,6 256,4 |
160 160 |
--- --- |
--- --- |
||
F1 = force extending when extend the cylinder | F2 = force retracting when retraction the cylinder
FAQ - Standard cylinder DIN/ISO
General questions
- What is the difference between an industrial hydraulic cylinder and a standard cylinder DIN/ISO?
-
An industrial hydraulic cylinder is based on manufacturer-specific optimized series and often offers more design flexibility. A standard cylinder DIN/ISO adheres to defined DIN or ISO mounting dimensions to ensure interchangeability across manufacturers.
- How does a double-acting hydraulic cylinder work?
-
A double-acting cylinder has two hydraulic ports for the cap side and the annular side. By pressurizing the cap side with hydraulic oil, the piston rod extends; if the annular side is pressurized, it retracts. This enables controlled force application and movement in both directions.
- Can the piston position of a standard cylinder DIN/ISO be detected?
-
Hänchen hydraulic cylinders can optionally be equipped with integrated position transducers. This enables precise and continuous detection of the piston position for control and regulation tasks.
