Hydraulic pressure reducer
For hydraulic low-pressure systems
When it comes to quickly moving or precisely regulating fluids with low pressure, pressure reducers are the right choice – for example, in the sensitive low-pressure testing of heat exchangers, fittings or hot water accumulators.
Hänchen advises you on the right pressure for your hydraulic application. Read more about this in our topic pages fluid separator and hydraulic pressure intensifier.
What distinguishes our pressure reducers:
- Compact construction
- Sensitively adjustable
- For all hydraulic fluids
- For fluids such as water, HFC, mineral oil or AdBlue®
Technical data for pressure reducers
Design proposals
| p2 [bar] |
D1 [mm] |
D2 [mm] |
Transmission ratio |
p1 [bar] |
|
15 |
16 20 30 |
60 80 125 |
0,07 0,06 0,06 |
211 240 260 |
|
25 |
20 25 40 |
60 80 125 |
0,11 0,10 0,10 |
225 256 244 |
|
40 |
25 30 50 |
60 80 125 |
0,17 0,14 0,16 |
230 284 250 |
All sizes and pressures on request.
Contact us, we will be happy to advise you!
